The company applies acrylic series water-based coatings on the surface of aluminum foil, which has the characteristics of strong adhesion, good oxidation resistance, perfect balance between strength and toughness, and long service life. It is very suitable for HVAC air conditioning ducts, wall, cold room and other humid environment. On the other side of aluminum foil, we use epoxy resin water-based coating, which is attached to the surface of aluminum foil. The coating help the aluminum foil to bond tightly with PU FOAM while running in sandwich panel production line.)
Material of mesh Polypropylene & polyethylene
Weight of mesh 10g/sq.m.
Secondary coating Light-curing & polyester type
Peeling strength to phenolic foam 15N/2cm.
Product Name | Non-Woven Coated Aluminum Foil |
Thickness | 0.025-0.2mm |
width | 1000-1300MM |
Outside Anti-oxidation Coating Weight | 1.5g - 6g/SQM |
Outside Color | Matte/Transparent/Black/White/Grey |
Inside Adhesion Coating Weight | 10g/SQM |
Inside Color | Blue/Gold/Pink |
coating | Material of mesh Polypropylene & polyethylene |
MOQ | 5 tons |
ID | 76/152MM aluminum or steel core |
Logo | Can be customized |
Roll weight | about 900kgs for coated foil |
Application | For HVAC |
Polyurethane &Phenolic Insulation panels for roof and wall | |
PUR Insulation panel for air duct | |
Polyurethane insulation panel for central air condition duct | |
PUR/PIR Foam Pre-insulated Duct Panel for central air condition duct | |
sandwich panel for air conditioning duct |
